Omnicor - NuTAP-R12G - IP performance testing tools

NuTAP-R12G

Xtramus NuTAP-R series is the high-level product which has port aggregation function at present Network monitor market. NuTAP-R series, the high level segment and rackmount form factor of NuTAP-R series, is the first network surveillance equipment that supports Gigabit Ethernet after NuTAP series. Its surveillance network port which has 2 or 4 Combo interfaces can support wirespeed forwarding of Gigabit Ethernet at the same time, Packet Capture, and Packet Re-direction functions.

Features
Active TAP based on monitor -and-forward architecture
Built-in filter to block traffic from specific network port(s) to the monitoring port (Individual 10 sets filter per port, R series and A series).
Design of web-based management interface makes the active friendly.
Filter support s 8-set 32bits UDF and 2-set 48bits UDF (offset fix at DA/SA).
Optional Redundant power (DC 48V power input module).
Provides the Statistic Counter (30 sets of individual counter per port).
Real-time LED indicator of traffic events and monitoring.
Redirect packet in Aggregation or Segregation mode.
Support full set RMON counter.
Support PoE Link automatically.
