Omnicor - NuDOG-301C (Optic Fiber) - IP packet generator - gigabit with combo ports RJ-45 & SFP

NuDOG-301C (Optic Fiber)

IP packet generator - gigabit with combo ports RJ-45 & SFP

NuDOG-301 is a handheld device with two Gigabit ports for Ethernet testing. The main functions of NuDOG-301 include multi-streams generation, TAP/Loopback test, and NIC emulation.

Features
512Mbits wirespeed packet capture buffer per port
Hardware based wirespeed streams generation, analysis, network TAP and NIC
High precision 1 ppm temperature-compensated oscillator provides accurate clock speed to ensure the reliability of the tests
High precision performance for measuring throughput, latency, packet loss and disordered sequence
Injecting errors in transmitted traffic to simulate and test abnormal situations
Layer 1 and Layer 2 loopback test
Real-time statistics for each port, including transmitted/received frame for VLAN, IPv4, IPv4 fragment, IPv4 extension , ICMP, ARP, total bytes/packets, CRC, IPCS error and over-and-under size frames
RFC 2544 test suite
RFC 2889 test suite
User-friendly interface that supports various parameter configurations and meets various test requirements
Wirespeed traffic capturing with programmable filter and trigger criteria
