  • NuStreams 700 Ethernet Test System

NuStreams 700 Ethernet Test System

Modular Chassis 700 - 7 slot Portable for R&D or production

Xtramus NuStreams chassis NuStreams-700 is an ideal test beds for lab design, troubleshooting and mass production test of network products. Supports 10G Ethernet, Gigabit Ethernet and 10/100 Mbps Ethernet.

  • Features
  • Comprehensive temperature and Fan speed monitoring with visual indicators
  • Multi-user application support
  • Reduce test duration time, easily test RFC2544/2889 compliance, and create regression tests without programming
  • Replaceable fan tray
  • Simple and Easy to read LED provides system status
  • Supports 10/100/1000 Mbps (half / full duplex in 10/100 mode) Ethernet connections to a host PC, and can be set for auto-negotiation or speed is completely configurable
  • Supports hot swap of all test modules
  • Supports multi-user per test module for greater efficiency of hardware resource
  • Synchronization auto calibration between test modules
  • Works with the XTRAMUS software applications for comprehensive functional testing, conformance testing and performance analysis all in one system
  • Specifications
Dimension: 23.7cm X 22.0cm X 19.2cm
Humidity: Operating: 0% ~ 85% RH
Storage: 0% ~ 85% RH
Interface: Ethernet: RJ-45 Gigabit port x 2
Power: Male IEC 320 receptacle
Miscellaneous: Built-in sensor for detection of temperature and rotation speed of fans.
LED for each module shows the running status of installed module
New weight: Approx. 3.2kg
Power consumption: 250 Watt
Power source: AC 90V ~ 240V, 50Hz ~ 60Hz
Slot: 7 for test modules
Software support: APMPT-4
Other software supported by Xtramus
Temperature: Operating: -10°C~ 50°C (14°F~ 122°F)
Storage: -10°C~ 50°C (14°F~ 122°F)

  • Applications
  • Performance validation and analysis of DUT
  • Production testing and quality assurance during manufacturing process of network products
  • Troubleshooting of DUT in the lab
NuStreams 700 Ethernet Test System-diagram
