Omnicor - NuTAP-L12G - IP performance testing tools

NuTAP-L12G

Xtramus NuTAP-L series is the high-level product which has port aggregation function at present Network monitor market. NuTAP-L series, the high level segment and rackmount form factor of NuTAP series, is the first network surveillance equipment that supports Gigabit Ethernet after NuTAP. Its surveillance network port which has 2 or 4 UTP interfaces can support wirespeed forwarding of Gigabit Ethernet at the same time, and Packet Re-direction functions.

Features
Active TAP based on monitor -and-forward architecture
Design of web-based management interface makes the active friendly.
Loopback test function test the transmission and route problem of network.
Optional Redundant power (DC 48V power input module).
Provides the Statistic Counter: Rx Frame, Tx Frame, Collision, CRC Error, Alignment Error, Dribble Error, Oversize, Undersize, Broadcast, Multicast, Packet size (64~1518), Pause, 256 streams VLAN, Frame Rate and other RMON counters.
Real-time LED indicator of traffic events and monitoring.
Redirect packet in Aggregation or Segregation mode.
Support PoE Link automatically.
