Test Module XM-RM891 - Standard

XM-RM891 is 1 Port 10Gbps XFP Ethernet standard Test Module with high test quality and reliable test result. It can generate 64 sets of Rapid-Matrix stream traffic simultaneously per port for the test that is similar to real network condition.

Features
1 XFP fiber port per module and they are expandable with more module in the same chassis.
Flexible contents (data) and length for the generation of packet payload.
Flexible Frame size from undersize to oversize frame can be generated and tested for different kinds of DUT
Fully RMON counter and VLAN counter for analysis of test result after receiving of generated packets.
Generation and response to ARP and Ping for layer 3 testing
Rapid-Matrix function that can generate multi-stream traffic simultaneously per port for the test that is similar to real network condition.
SDFR (Self-Discover Filtering Rules) technique that criteria for filter can be input directly without calculating mask.
Statistics analysis counters for received multi-stream traffic.
Test module for 10 Gigabit Ethernet equipment with fiber connection.
Verify oscillator\'s speed rate of DUT
Verify oscillator\\\'s speed rate of DUT
Wirespeed generation and analysis of Layer 2-3 packets in 10 Gigabit Ethernet
Xtramus\'s proprietary embedded tag, X-TAG for sequence check and latency measurement of packets per stream in Rapid-Matrix.
Xtramus\\\'s proprietary embedded tag, X-TAG for sequence check and latency measurement of packets per stream in Rapid-Matrix.

Applications
Apply to Telecommunication room, R and D laboratory, Data center, etc.
Test module for 10 Gigabit Ethernet device.
Test module for new design network product in R and D laboratory that need report of precise statistics and result.
Test module for quality control of network device in mass production line.
